Structural Steel Detailing

Structural steel detailing plays an important role in successfully handling the requirements of material, manpower, equipment and tools on site for fabricators. The up-to-date software used by TSS in 3D modeling, 2D drafting and steel fabrication drawings detects any clash or extraneous part in a structure during the initial stages, which helps our clients remedy it at the planning phase itself. When you give us the task of doing the design of steel structures, we make sure there is no miscommunication among the architects, engineers and contractors resulting in a vibrant team bonding throughout the project.

Using the latest 3D Modeling Software from Tekla, we provide Models, Erection and Shop Detail drawings along with Material Lists in various formats including EJE and KSS.

A great benefit of using 3D software is our ability to produce CNC and DXF files directly from the model for automated fab shops if needed.

Our goal is to provide high quality drawings ready for fabrication to accommodate the customer’s needs and schedule

International codes and standards we follow

• AISC – American Institute of Steel Construction
• OSHA – Occupational Safety and Health Administration
• AWS – American Welding Society
• CISC - Canadian Institute of Steel Construction
